H-起升高度 Hoisting height
V1-起升速度 Hoisting speed
V2-小車運行速度 Traveling speed of trolley
V3-大車運行速度 Traveling speed of crane
L1-起重機左極限 Left limit of crane
L2-起重機右極限 Right limit of crane
C1-起重機兩端*小極限 Minimum limit of both ends
C2-起重機頂部*小極限 Minimum limit of top of crane
S-起重機跨度 Crane span
H1-起重機小車鉤心到頂部的距離 Distance between core of hook and its top
H2-起重機小車的高度 Height of trolley
H3-起重機底部到大車軌道面的距離 Distance between the bottom of crane and crane rail plane
H4-起重機緩沖器到大車軌道面的距離 Distance between buffer of crane and crane rail plane
H5-起重機頂部到大車軌道面的距離 Distance between the top of crane and crane rail plane
W-起重機*外兩個車輪之間的距離 Distance between two outmost wheels of crane
W1-起重機一角*外兩個車輪之間的距離 Distance between two outmost wheels of one corner of crane
W2-起重機臺車兩個車輪之間的距離 Distance between two wheels of trolley
B-起重機*外車輪距離緩沖器端部之間的距離 Distance from the outmost wheel to ends of buffer
b-起重機*端部距離大車軌道之間的距離 Distance from ends to rail of crane
G-起重機整車的重量 Overall weight of crane
K-起重機*大輪壓 Maximum wheel pressure of crane
P-起重機總的功率 Total power of crane
選型說明
1、本產品系列表僅列出了常用的基本的規格起重機,工作級別為A5(FEM 2m)時的標準跨度,沒有副鉤的室內用起重機??蛻?hù)根據需要可以提出相應的要求。
2、本系列也可以增加副起重機構,也可以增加輕載時速度加倍的設置,一般主副的設置為4:1,也可以根據客戶的要求設定。囚設置副鉤則起重機的總重及輪壓會(huì )有所增加。
3、表中的尺寸,重量,輪壓供客戶訂貨時參考,如果客戶的需要條件發生變化,如工作級別,速度,起升高度有變化時,相應的參數,尺寸,重量,輪壓等都會(huì )發生變化,實際的參數,質量,輪壓以合同的要求為準。
4、表中列出的起升速度,大小車速度為標準值,可以根據客戶的需求做相應的調整。
5、技術參數及尺寸會(huì )因為技術的改進或者升級有所變化,如有疑問的話可以和公司技術部聯系。
